| Part Number | 4 wire resistive:TM-1705A-4RHD 5 wire resistive:TM-1705A-5RHD Projected capacitive:TM-1705A-CTHD Infrared:TM-1705A-IRHD Surface acoustic wave:TM-1705A-AWHD |
| Enclosure Color | Silver |
| Touch Technology&Touch Point | 4 wire resistive:single touch 5 wire resistive:single touch Projected capacitive:10-point touch Infrared:2/4 point touch(optional) Surface acoustic wave: Single touch |
| Touch Interface | RS232/USB2.0 |
| Diagonal | 17"Diagonal,Ratio5:4,Active matrix TFT LCD, LED backlight |
| Display screen (OSD) | Visit via turn on/off button in OSD. Control unit:menu,up,down,exit,power OSD:contrast ratio,brightness,horizontal/vertical,RGB,time,phase,select default value,language (English,Germany, Spanish, Japanese,French),OSD validate/invalidate,power,OSD men |
| Screen Ratio | 5:4 |
| Acitive Area (mm) | 337.9mm x 270.3mm |
| Resolution | 1280 x 1024 |
| Other resolutions | 1024 x 768 ; 800 x 600; 720 x 400 ;720 x 350; 640 x 480,60 Hz; |
| Viewing angle | Horizontal (left / right): ± 80 ° or total 160 ° Vertical (up / down): ± 70 ° or a total of 140 ° |
| Color Pixel | 16.2m |
| Brightness(Typ.) | LCD panel:250 nits 4-wire resistive/5-wire resistive:200nits(Typ.) Projected Capacitive/Surface Acoustice Wave/Infrared 250nits(Typ.) |
| Response time (standard) | 5ms |
| Contrast ratio (standard) | 1000:1 |
| Video input frequency | Horizontal:31.5-60.2kHz;Vertical:56.3-75Hz |
| Video Interface | HDMI,VGA,DVI |
| Power | Externel DC-Optional adapter |
| Power Input Interface | INPUT POWER CONNECTOR SPECIFICATIONS (for all in one PC)-Type: DC cartridge receptacle;Cartridge ID:5.5mm(±0.3mm);Needle OD:2.0mm(+0.0-0.1mm); Cartridge depth:8(±0.3mm).External DC,input voltage DC:12V Power connector(on power adapter)-Type:DC cartridge Plug:Cartridge OD:5.5mm(±0.1mm)；Needle Inner Diameter:2.1mm(±0.1mm); Cartridge Length:9.5mm(±0.5mm) |
| Input Voltage | 12VDC+/-5% |
| Power Consumption(Typ.) | Monitor+Adapter 2230V/50Hz Working:15W Sleep:1.5W Turn-off:0.5W |
| Dimensions | 4-wire/5-wire resistive touch:262.0mm X300mmX48mm Projected capacitve touch:300mmX320mmX48mm Infrared Touch:376mmX308mmX53mm SAW touch:388mmX320mmX50mm |
| Dimensions for Shipping | 510mmX435mmX125mm |
| Net Weight | 4.3kg |
| Gross Weight | 5.8kg |
| Working Temperature | 0℃ to 40℃/32°F to 104°F |
| Storage Temperature | -20℃ to 60℃,-4°F to 140°F |
| Humidity | Working:20% to 80% Stocking:10% to 95% |
| Tightness | Touch panel seal to bezel LCD Touch panel seal to LCD |
| MTBF | 50000 hours |
| Warranty | 1 year |
| Institute Certificates | UL,A1:B30cUL(Recognized),FCC,CE,China RoHS |
| Installation Methods | 100mm or 75mm VESA Install:Open frame installation kit |
| Content in package | Product data sheet With bezel:L-shape install kit and W-shape crews Quality Cetificates Warranty card |
| Opeional/External devices | HDMI cable DVI cable VGA cable Touch USB cable North America Power cable Europe&South Korea Power cable Britain Power cable China Power cable Taiwan Power cable Japan Power cable Argentina Power cable |
